| Content |
| Test Voltage |
14.4 |
| Channels |
4 |
| Cont Wattage @ 4ohm |
90x4 / 240x2 |
| Cont Wattage @ 2ohm |
120x4 |
| Max Current Draw - Amperage |
45 |
| S/N Ratio |
>80dB |
| THD |
<0.3% |
| Input Voltage Sensitivity |
200mV - 6V |
| Pass-Through Output |
Yes |
| Remote Subwoofer Control |
No |
| Power Wire Guage In |
4 |
| Speaker Wire Gauge Out |
12 |
| Dimensions: in |
9 x 5 x 2 |
| Dimensions: mm |
233 x 125 x 47 |
|
| Test Voltage |
12 / 14.4 |
| Channels |
1 |
| Cont Wattage @ 4ohm |
N/A |
| Cont Wattage @ 2ohm |
N/A |
| Cont Wattage @ 1ohm |
700x1@12V / 900x1@14.4V |
| Max Current Draw - Amperage |
100 |
| S/N Ratio |
>100dB |
| THD |
<0.02% |
| Input Voltage Sensitivity |
8 - 0.2 |
| Pass-Through Output |
Yes |
| Remote Subwoofer Control |
Yes |
| Power Wire Guage In |
1 x 0 |
| Speaker Wire Gauge Out |
10 |
| Dimensions: in |
11 x 6.9 x 2.03 |
| Dimensions: mm |
27.94 x 17.53 x 5.16 |
| Shipping Weight - lbs |
10 |
|
| Test Voltage |
14.4V |
| Channels |
1 |
| Cont Wattage @ 4ohm |
210 |
| Cont Wattage @ 2ohm |
380 |
| Cont Wattage @ 1ohm |
500 |
| Dynamic Wattage |
800 |
| Max Current Draw - Amperage |
80A |
| S/N Ratio |
>80dB |
| Input Voltage Sensitivity |
4V-0.1V |
| Pass-Through Output |
Yes |
| Remote Subwoofer Control |
Yes |
| Power Wire Guage In |
4 |
| Speaker Wire Gauge Out |
12 |
| Dimensions: in |
7.87 x 4.92 x 1.85 |
| Dimensions: mm |
200 x 125 x 47 |
|
| Test Voltage |
14.4 |
| Channels |
1 |
| Cont Wattage @ 4ohm |
810 |
| Cont Wattage @ 2ohm |
1400 |
| Cont Wattage @ 1ohm |
2500 |
| Dynamic Wattage |
3000 |
| Max Current Draw - Amperage |
300 |
| S/N Ratio |
>85dB |
| Input Voltage Sensitivity |
4 - 0.1V |
| Pass-Through Output |
Yes |
| Remote Subwoofer Control |
Yes |
| Speaker Wire Gauge Out |
10 |
| Dimensions: in |
19.68 x 7 x 2 |
| Dimensions: mm |
500 x 175 x 55 |
| Shipping Weight - lbs |
8 |
|
| Test Voltage |
14.4 |
| Channels |
4 |
| Cont Wattage @ 4ohm |
60x4 / 170x2 |
| Cont Wattage @ 2ohm |
85x4 |
| Max Current Draw - Amperage |
35 |
| S/N Ratio |
>88dB |
| THD |
<0.18% |
| Input Voltage Sensitivity |
150mV - 5V |
| Pass-Through Output |
Yes |
| Remote Subwoofer Control |
No |
| Power Wire Guage In |
2 x 18 |
| Speaker Wire Gauge Out |
18 |
| Dimensions: in |
6.3 x 4 x 1.77 |
| Dimensions: mm |
160 x 105 x 47 |
| Shipping Weight - lbs |
2 |
|
| Test Voltage |
14.4V |
| Channels |
4 |
| Cont Wattage @ 4ohm |
60x4 / 180x2 |
| Cont Wattage @ 2ohm |
90x4 |
| Max Current Draw - Amperage |
40A |
| S/N Ratio |
>86dB |
| THD |
<0.20% |
| Input Voltage Sensitivity |
8V-0.25V |
| Pass-Through Output |
Yes |
| Remote Subwoofer Control |
Yes |
| Power Wire Guage In |
4 |
| Speaker Wire Gauge Out |
12 |
| Dimensions: in |
12.5x7x2 |
| Dimensions: mm |
318x175x54 |
|
